ELECTROVAP® ELMC
22
Unit switch: when the unit is switched off, there is still high voltage inside the
unit. Electric shock may be fatal, electrical isolator must be switched off.
Humidifier electrical compartment
Power supply: Installation of an electrical
isolator with fuse protection, or ground-
fault circuit interrupter according to local
regulations (equipment not supplied).
Power cable (not supplied)
Unit Switch
Fig. A 3-7. Electrical connections
