Devatec ElectroVap - Drain Hose Installation with Funnel

ELECTROVAP® ELMC
20
A funnel can also be used (see picture below), but it should be offset from the underside of the unit to prevent
any steam and/or condensation from getting into the cabinet.
CAUTION: keep a minimum downward slope of 10° for both the draining & overflow hoses of the humidifier
and for the general drain pipe.
Fig. B 3-6. Example of Installation with funnel
