DeVilbiss 1025 Series - Device Specifications

EN - 10
SPECIFICATIONS
DEVILBISS 10-LITER SERIES
Catalog Number 1025DS 1025KS
1025UK
Delivery Rate 2 to 10 LPM 2 to 10 LPM 2 to 10 LPM
Maximum Recommended Flow (@
nominal outlet pressures of zero and
7 kPa)**
10 LPM 10 LPM 10 LPM
Outlet Pressure 20.0 ± 1.0 psi (138 kPa +/- 7 kPa) 20.0 ± 1.0 psi (138 kPa +/- 7 kPa) 20.0 ± 1.0 psi (138 kPa +/- 7 kPa)
Electrical Rating 120 V, 60 Hz, 6.1 Amp 230 V~, 50 Hz, 3.2 Amp 240 V~, 50 Hz, 3.2 Amp
Operating Voltage Range 102-132 V~, 60 Hz 195-253 V~, 50 Hz 204-264 V~, 50 Hz
Oxygen Percentage 2-10 LPM=87%-96% 2-10 LPM=93% +3%/-6% 2-10 LPM=93% +3%/-6%
Operating Altitude
(tested at 70˚F {21˚C} only)
0-1500 M (0-5000 ft)
Across the voltage range:
No degradation of performance
Across the voltage range:
No degradation of performance
Across the voltage range:
No degradation of performance
Operating Environment Range*
41˚F (5˚C) to 95˚F (35˚C), humidity
range of 15% to 93% non-
condensing
No degradation in performance across
the operating voltage range.
No degradation in performance across
the operating voltage range.
No degradation in performance across
the operating voltage range.
Power Consumption 120 vac, 60HZ: 639 watts average 230 vac, 50Hz: 664 watts average 240 vac, 50Hz: 670 watts average
Weight 42 lbs. (19 Kilograms) 42 lbs. (19 Kilograms) 42 lbs. (19 Kilograms)
Safe Working Load 53 lbs. (24 Kilograms) 53 lbs. (24 Kilograms) 53 lbs. (24 Kilograms)
Sound Pressure Level at 3 and 10LPM
<59 dBA <57 dBA <57 dBA
Sound Power Level at 3 and 10 LPM <69 dBA <67 dBA <67 dBA
Dimensions
24.5”H x 13.5”W x 12”D
(62.2 x 34.2 x 30.4 cm)
24.5”H x 13.5”W x 12”D
(62.2 x 34.2 x 30.4 cm)
24.5”H x 13.5”W x 12”D
(62.2 x 34.2 x 30.4 cm)
Maximum Limited Pressure 35 PSIG (241 kPa) 35 PSIG (241 kPa) 35 PSIG (241 kPa)
Operating System Time Cycle / Pressure Swing Time Cycle / Pressure Swing Time Cycle / Pressure Swing
The visible “low oxygen” indicator
will activate at the following level
86% ± 3%
(The audible alarm will alert at
approximately 85%. At less than 60%, the
red “service required” light will activate.)
86% ± 3%
(The audible alarm will alert at
approximately 85%. At less than 60%, the
red “service required” light will activate.)
86% ± 3%
(The audible alarm will alert at
approximately 85%. At less than 60%, the
red “service required” light will activate.)
Storage Conditions -13˚F (-25˚C) to 158˚F (70˚C), humidity
range of 15% to 93% non-condensing,
including condensation
-13˚F (-25˚C) to 158˚F (70˚C), humidity
range of 15% to 93% non-condensing,
including condensation
-13˚F (-25˚C) to 158˚F (70˚C), humidity
range of 15% to 93% non-condensing,
including condensation
Equipment Class and Type
Class II Equipment Double Insulated;
Type B Applied Part
Ordinary Equipment, IP21
Class II Equipment Double Insulated;
Type B Applied Part
IP21
Class II Equipment Double Insulated;
Type B Applied Part
IP21
Approval Body and Safety Standard
TUV
IEC 60601-1 3rd Edition
In Process
TUV
IEC 60601-1 3rd Edition
IEC 60601-1
IEC 60601-1-11
ISO 80601-2-69
TUV
IEC 60601-1 3rd Edition
IEC 60601-1
IEC 60601-1-11
ISO 80601-2-69
CE mark No Yes Yes
EMC Compliance To EN60601-1-2 EN60601-1-2 EN60601-1-2
*NOTE– The OSD performance at 41˚F (5˚C) to 95˚F (35˚C), 95% R.H. through voltage range on the 1025 veried at 670m.
**The maximum recommended ow is 6 LPM when an oxygen bottle is being lled with oxygen from the auxiliary oxygen port.
Specications subject to change without notice.
Oxygen Concentration vs Flow Rate
Flow L/m
%O
2
10 87% - 92%
9 87% - 93%
8 87% - 95%
7 87% - 96%
6 87% - 96%
5 87% - 96%
4 87% - 95%
3 87% - 95%
2 87% - 94%
A-1025
