23
LT-2027
EN
Unit Specifi cations
Size 4.2” H x 6.5” W x 6.9” D (10.7 cm x 16.5 cm x 17.5 cm)
Weight 2.7 lbs. (1.22 kg)
Electrical Requirements 100-240V~, 50/60 Hz
DC Operation 12 Volt, 5 Amps
Maximum Power Consumption 65 watts max from AC power source (PAP device only)
AutoAdjust CPAP Pressure Range 3-20 cmH2O
Operating Temperature Range 41°F to 104°F (5°C to 40°C)
Operating Humidity Range 0% to 95% RH non-condensing
Operating Atmospheric Conditions Sea level to 9,000 feet
Storage & Transportation Temperature Range -40°F to 158°F (-40°C to +70°C)
Storage & Transportation Humidity Range 0% to 95% RH non-condensing
Maximum Limited Pressure 20 cmH2O under normal use
Sound Level (tested per ISO 17510) 26 dBA
Filter Specifi cations
Standard Filter > 3.0 micron particles
Optional Fine Particle Filter > 0.3 micron particles
Max Flow Rates
83 L/m @ 6.5 cmH2O (1/3 max pressure)
134 L/m @ 13 cmH2O (2/3 max pressure)
163 L/m @ 20 cmH2O (max pressure)
Pressure Accuracy ± 1.0 cmH2O
Pressure Swings
(cmH2O peak to peak at 500mL tidal volume, sine wave profi le)
Breaths per
minute
10 15 20
@ 6.5 cmH2O 0.5 0.5 0.5
@ 13 cmH2O 1.0 1.0 1.0
@ 20 cmH2O 1.0 1.0 1.0
Other Specifi cations
Equipment classifi cation with respect to protection from electric
shock
Class II
Degree of protection from electric shock Type BF Applied Part
Degree of protection against ingress of liquids IPX1
Equipment not suitable for use in the presence of a fl ammable anesthetic mixture
with air or with oxygen or nitrous oxide.
Mode of operation Continuous
Clinical Specifi cations for Digital Outputs
Mask pressure 0 to 25.5 cmH2O ± 1.0
Patient Flow -127 to +127 L/min ± 10L/min
Leak Flow
0 to +127 L/min ± 10 L/min
Estimated Tidal Volume 0 to 1023 mL
Note– Tidal Volume is an estimate. It is provided for trending purposes only.
10. U nit Specifications
