28 Network configuration
devolo GigaGate
80 MHz: Default setting. Suitable for the WiFi standard
802.11ac. Up to five non-overlapping channels are
available here.
Reading MAC address of the devolo GigaGate
Base
5 GHz Bridge monitor
Connected Bridge devices
Here, the connected devolo GigaGate Base is shown
with the MAC address and the date of the last login.
The MAC address provides a unique identifier
for the hardware interface of every individual
network device (e.g. the WiFi adapter of a com-
puter or Ethernet port of a printer). It consists of
six two-digit hexadecimal numbers, each sepa-
rated by a colon (e.g. 00:0B:3B:37:9D:C4).
Deactivating the WiFi function of the
devolo GigaGate Satellite
WiFi status Access point
Wi-Fi on/off
Using the on/off switch, the WiFi function of the
devolo GigaGate Satellite can be switched on and off
manually. After clicking OK, the WiFi function of the
device is deactivated.
The WiFi function of the
devolo GigaGate is enabled by de-
fault.
Changing the network name (SSID)
Bridge network name
The Bridge network name determines the name of
your wireless network. You can see this name when
logging onto the WiFi, allowing you to identify the cor-
rect WiFi network.
Here, you can customise the WiFi network name (SSID)
manually. This network name is important for connect-
ing to other WiFi-compatible devices later on.
Hiding the network name (SSID)
Hide SSID yes/no
If you enable the Hide SSID option, your wireless net-
work remains hidden. In this case, potential network
users must know the exact SSID and enter it manually
to be able to set up a connection.
Some WiFi adapters have difficulty connecting
to such hidden wireless networks. If the connec-
tion with a hidden name poses problems, first
try setting up the connection with a visible net-
work name and then hiding the network name
afterwards.

Other manuals for Devolo GIGAGATE

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Devolo GIGAGATE and is the answer not in the manual?

Devolo GIGAGATE Specifications

General IconGeneral
DSL WANNo
Ethernet WANYes
ModulationOFDM
Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
Wi-Fi standards802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standardWi-Fi 5 (802.11ac)
WLAN data transfer rate (max)1733 Mbit/s
WLAN data transfer rate (first band)300 Mbit/s
Product typeTabletop router
Product colorBlack
LED indicatorsLAN, Link, Power, WLAN
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates10, 100, 1000 Mbit/s
Ethernet LAN interface typeGigabit Ethernet
Memory card slot(s)-
Ethernet LAN (RJ-45) ports5
Output voltage12 V
Power source typeAC
Power consumption (typical)9.1 W
Package depth243 mm
Package width190 mm
Package height110 mm
Package weight1200 g
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)10 - 90 %
Security algorithmsWPA, WPA2
Cables includedAC, LAN (RJ-45)
Weight and Dimensions IconWeight and Dimensions
Depth140 mm
Width150 mm
Height30 mm
