3736
NOMAD
Device Symptom Potential Problem Corrective Action
6.2.4 Device does not
shift to the Enabling
X-rays alert or Ready
alert.
The trigger is pulled for
longer than one second.
Pull and release the trigger within one
second and wait for the Ready alert.
The device may be above
the maximum operating
temperature of 104°F
(+40°C).
Allow the device to return to the operating
range as stated in Section 8.
6.2.5 Image from X-ray
exposure does not have
sufficient contrast.
Underexposure (too light).
Increase the exposure time setting; or see
“Incomplete Exposure” below.
Overexposure (too dark).
Decrease the exposure time setting. Also
check film expiration date (old film can
produce dark, grainy/foggy images).
Chemical developer (for
film-based imaging).
Ensure chemical freshness and proper
temperature.
6.2.6 Image from X-ray
exposure is blurred.
Combined movements
of operator and patient
during exposure produced
too much distortion.
Check the exposure time setting and re-
enable when operator and patient are again
properly situated.
6.2.7 Charging Cradle
shows Red LEDs.
Alternate Red and Green
LEDs are shown on
the charger when first
plugged in.
This is the standard startup process to test
the display. There is no problem with the
charger.
If the LEDs are solid red
with no attached Handset,
there may be Infra Red
(IR) communication
interference.
Unplug the power from the charging cradle,
wait 5 seconds, and re-connect. If the
problem persists, relocate the charging
cradle as the cause may be environmental
(Fluorescent lights, computer monitors, etc.)
If the LEDs are solid red
with a handset attached,
there may be an
intermittent interference.
Remove the handset, wait 5 seconds, and
replace. If the issue persists, attempt to
relocate the Charger as described above.
If the LEDs are flashing
red, the handset has
been stored above it’s
operating temperature.
Remove the handset from the charger and
allow to cool. Once cooled, the handset can
be charged. Evaluate storage processes and
temperatures.
If the LEDs are solid
red the charger may be
incompatible
Refer to 6.2.1 information regarding
incompatible components.
If this condition persists, authorized service is
required. See Section 7.0 Maintenance and
Repair.
6.2.8 System Failure
alarm displayed
on-screen.
Self-diagnostics, which
automatically run during
X-ray firing, detects a
potential issue.
This warning alarm can be cleared
by powering off, then on. If the alarm
redisplays, the NOMAD Pro 2 will require
authorized service; see Section 7.0
Maintenance and Repair.
