Wiring Group

Key Part Number Description Quantity

* 9627-911-001 Wiring Harness- Main Power ................................................ 1

* 9631-403-001 Wire, Hi Voltage, Spark 38”................................................... 2

* 8502-645-001 Label Instruction ....................................................................1

* 9506-544-001 Wiring Label Schematic/Diagram ......................................... 1

* 9627-860-001 Wire Harness Ignition Upper Low Voltage ........................... 1

* 9627-860-002 Wire Harness Ignition Lower Low Voltage ........................... 1

* 9627-863-001 Wire Harness Main Extension .............................................. 1

* 9627-864-001 Wire Harness Motor Extention .............................................2

* 8220-062-036 Wire Assembly Red/Black 14”...............................................1

* 8220-062-037 Wire Assembly Red/White 14” .............................................. 1

* 8220-062-038 Wire Assembly White 14” ...................................................... 2

* 9627-861-001 Wire Harness - Overtemp / Airswitch ................................... 2

* 9627-862-001 Wire Harness Main Controller w/ Door Switch Wires ........... 1

* 9627-855-003 Wire Harness - Heat Sensor ................................................ 1

* 8527-112-001 Decal Lighting and Clearance ............................................... 1

* 8502-763-001 Label Warning & Notice ........................................................2

* 8502-764-001 Label Warning Dryer, FRN/SPN ........................................... 2

* 9506-544-001 Schematic /Diagram .............................................................. 1

* 8514-233-001 Operators Manual ................................................................. 1

* 8507-365-001 Instructions Convert Dual Voltage ....................................... 1

* 8507-330-001 Instruction Transient Voltage Suppressor ............................ 1

* 8507-350-001 Instructions Dryer Install / Start ........................................... 1

* 8220-137-001 Wire Assembly Green 24” ..................................................... 1

* 8220-001-466 Wire Assembly Yellow 4 7/8” Gas Valve ..............................2

* 8220-095-038 Wire Assembly Orange 48” ................................................... 2

* 9506-544-001 Wiring Schematic/Diagram ...................................................1

* 8220-095-040 Wire Assembly Orange 24” ................................................... 1

* 8220-095-041 Wire Assembly Brown 24” .....................................................1

* 9052-067-002 Bushings Wire 7/8” ................................................................ 4

Part # 8533-090-001 7/21
