Rear Panel & Cover Group
Key Part Number Description Quantity
1 9208-124-001 Back Drive Guard Panel .................................................... 2
2 9208-123-001 Back Side Guard Panel (Before Serial D1.19219.026) ........... 2
* 9208-073-001 Guard, Small Lower (Before Serial D1.19219.026) ................ 1
* 9208-074-001 Guard, Small Upper (Before Serial D1.19219.026) ................ 2
* 9545-008-024 Screw, Guards.........................................................................28
* 9074-365-001 Cabinet (TOP COVER) ...................................................... 1
* 8544-006-001 Legs Leveling................................................................... 4
4 9108-117-001 Electric Box Cover ........................................................... 6
5 9545-008-024 Screws 10 AB x 3/8 .......................................................... 4
6 9109-113-001 Top Duct w/ Round .......................................................... 1
7 9074-364-001 Lower Duct Cover ..................................................................1
* 9545-008-024 Screws 10AB x 3/8..................................................................14
* 9973-034-001 8” Slide Open Clean Out Duct (Optional)................................1
8 9550-173-001 Burner Inlet Shield ........................................................... 1
* 9545-008-024 Screws 10AB x 3/8 ........................................................... 3
92
Part # 8533-090-001 7/21
