2. Loosen the four mounting bolts on the side channels.
3. Open the clothes door and insert a 1/2” thick shim at the 3 and 9 o’clock positions and a 1/4”
thick shim at the 6 o’clock position.
4. Tighten the two bottom adjusting nuts and tighten locking nuts.
5. Tighten the bottom right mounting bolt, then the top left mounting bolt. Tighten the remaining
two bolts. (Shim where and if necessary.)
6. Tighten the two top adjusting bolts.
7. Remove all the shims from between the front panel ange and cylinder (3, 6, and 9 o’clock).8.
Spin the cylinder to check for rubbing baes, pressing down hard while rotating. If rubbing is
detected, repeat procedure paying particular attention to placement of shims between bearing
housing and side channels.
Tumbler Through Bolt Access Cover
Remove 4 screws that mount the air ow switch to the back of the dryer. Remove 2 screws that retain
access cover. With access cover removed, tightness on the tumbler through bolts can be checked and
tumbler alignment can be adjusted.
Bearing Housing Removal
After removing cylinder as previously outlined, simply unbolt the bearing housing and remove.
65
