Ignition Module Removal
If the ignition modules are mounted on a bracket, see section A. Otherwise, see section B.
1. Remove all of the terminals of the wiring harness attached to the ignition module. Then, remove
the terminal of the hi-voltage cable attached to the ignition module.
2. Remove the mounting screws holding the ignition module in the control box.
Spark Electrode Assembly-Removal
1. Remove electrode cover and disconnect wires to electrodes.
2. Remove two screws to detach electrode assembly.
Gas Valve & Manifold Removal
1. Disconnect union at gas valve and disconnect wires from gas valve operator coils.
2. Remove right manifold mounting bracket screws and slide manifold to remove from left bracket.
Main Burner Orice Removal
1. Remove manifold and gas valve assembly as above.
2. Using an open end wrench, remove orices from manifold.
Main Burner Removal
1. Remove the 4 screws securing the cover for the burner housing and the one screw mounting the
high limit cover. With the burner housing cover removed, there is complete access to the burner
assemblies.
Recirculation Chamber Inspection
1. Remove Resettable manual overtemp sensor and remove inspection plate in burner chamber
between main burners and rear back panel of dryer.
Cylinder Removal
1. Remove the front panel in front of the cylinder.
2. Remove drive belt, pulley, and key from cylinder shaft.
3. Pull the cylinder from the front of the machine.
Adjustment Of Cylinder Assembly With Front Panel Removed
1. Loosen the two top adjusting bolts and two bottom adjusting nuts and lock nuts holding the
bearing housing to the drive plate.
64
Part # 8533-090-001 7/21
