Dexter Laundry DC30X2NC-39AC1X User Manual

Parts Data
Cabinet Group
Key Part Number Description Quantity
* 9960-256-038 Door Assy., Loading Complete-Wht .................................. 2
* 9960-256-039 Door Assy., Loading Complete-SS ..................................... 2
* 9960-256-035 Door Assy., Loading Complete-Chrome SS/CHR/BLK .......... 2
1 9960-255-008 Door Assy., Loading-SS(ring only) ..................................... 2
1 9960-255-016 Door Assy., Loading-Chrome(ring only) ............................. 2
2 9982-280-014 Plate Assy., Hinge (Wht) No Pin ....................................... .2
2 9982-280-012 Plate Assy., Hinge (SS) No Pin ........................................... 2
* 9545-012-015 Screw, Hinge to Door ...................................................... 8
* 8640-413-002 Nut, Hinge to Door .......................................................... 8
3 9212-002-003 Glass, Door .................................................................... 2
4 9206-413-001 Gasket, Glass, Black ......................................................... 2
* 9548-117-000 Support, Door Glass ........................................................ 2
* 8545-064-001 Tool Install Dryer Glass Gasket ............................................. 1
5 9206- 420-003 Gasket, Outer Rim Black ................................................... 2
6 9244-082-001 Handle, Loading Door ...................................................... 2
* 9545-018-017 Screw, Handle 1/4-20 x 3/8 .............................................. 2
* 9531-033-001 Stud, Door Catch ............................................................ 2
* 8640-413-001 Nut, Hex ........................................................................ 2
* 8640-413-003 Nut, Acorn ..................................................................... 2
* 9086-015-002 Catch, Loading Door ...................................................... .2
* 8638-190-009 Pop Rivet for mtg. catch .................................................. 4
* 8641-582-006 Lockwasher ..................................................................... 4
* 8640-399-001 Spring Nut ..................................................................... .6
7 9989-569-003 Panel Assy., Front- Lower (Wht) (LRG Vault) ....................... 1
7 9989-569-001 Panel Assy., Front- Lower (SS) (LRG Vault) ......................... 1
8 9989-568-003 Panel Assy., Front- Upper (Wht) ....................................... 1
8 9989-568-001 Panel Assy., Front- Upper (SS) ........................................ .1
9 9545-008-014 Screw Phillips 10B x 1 3/4” ................................................ 8
* 8640-442-001 Nut Expansion (After Serial D1.19219.026) ......................... 8
10 8641-585-001 Washer Finish ................................................................. 8
11 9544-072-002 Strap, Hinge (Black) ........................................................ 2
* 9452-819-001 Plate Hinge Backup.................................................................2
* 9545-012-028 Screw, Hinge to Panel ..................................................... 8
12 9545-052-001 Screw, Door to Hinge Strap (Special Black Type) .............. .2
* 8641-436-003 Washer, Fiber ................................................................. 2
13 9021-041-001 Acceptor-Coin, Optical ..................................................... 1
* 9486-149-001 Retainer, Coin Acceptor ................................................... 2
14 9545-053-002 Screw ............................................................................ 4
* 9801-099-001 Switch, Optical (Replacement) ................................................1
* 9472-001-013 Cabinet Touch Up Paint (White)...............................................1
79
Part # 8533-090-001 7/21
