Cabinet Group Continued
Key Part Number Description Quantity
14 9994-046-001 Escutcheon, Upper .................................................................. 1
15 9435-061-002 Trim, Overlay-Upper, Blue ......................................................... 1
15 9435-061-001 Trim, Overlay-Upper, Black ........................................................ 1
* 9545-020-009 Screw, #4-40 x 3/16 ................................................................ 10
16 9994-048-001 Escutcheon, Lower .................................................................. 1
17 9435-063-002 Trim, Overlay-Lower, Blue ......................................................... 1
17 9435-063-001 Trim, Overlay-Lower, Black ........................................................ 1
* 9545-020-009 Screw, #4-40 x 3/16 ................................................................ 10
18 9412-167-002 Nameplate Stack Dryer Express, Blue ....................................... .1
18 9412-167-001 Nameplate Stack Dryer Express, Black ..................................... .1
19 8650-012-004 Lock and Key, Lint Drawer #6101 .............................................. 2
* 6292-006-010 Key 6101 only for Lint Drawer ................................................. AR
* 9095-043-001 Cam, Lock Lint Drawer ............................................................ .2
* 9627-859-003 Harness, Main-Electronic Control ............................................. .1
20 9857-198-002 Controls Assy, 24V, BLU ............................................................ 1
20 9857-198-004 Controls Assy, 24V, BLK ............................................................ 1
21 9435-038-002 Overlay-Control, Blue ............................................................... 1
21 9435-038-001 Overlay-Control, Black .............................................................. 1
22 8650-012-003 Lock and Key, Control #6324 .................................................... 1
* 9095-041-001 Cam, Lock .............................................................................. 1
* 6292-006-007 Key 6324 only for Computer ...................................................... 1
* 9150-045-001 USB, Thumbdrive............................................................................. 1
* 9627-855-001 Harness, Heat Sensor ............................................................... 1
* 8640-276-002 Wire Nut Connector Grey .......................................................... 4
23 9501-006-001 Sensor Temp Control (serial #200588) ....................................... 2
24 9486-137-002 Retainer - Push On ................................................................... 2
* 9209-037-002 Grommet, 3/16 ID .................................................................. 2
25 9866-004-001 Lint Drawer Assembly, Blue .................................................... . 2
25 9866-004-011 Lint Drawer Assembly, Black .................................................. . 2
26 9435-003-009 Overlay trim, lint drawer, Blue ................................................... 1
26 9435-029-001 Overlay trim, lint drawer, Black .................................................. 1
* 9532-143-001 Felt Seal ( back of lint screen assembly ) .................................. 2
* 9805-038-001 Lint Screen Assembly ONLY (no front) ....................................... 2
* 9555-057-002 Replaceable Lint Screen Only .................................................. .2
* 9545-008-001 Screws 10Bx 1/4 Lint Screen Strap Hold Down .........................32
* 8544-006-001 Leg, Leveling 1/2” .................................................................. 4
* 8545-061-002 Leveling Leg Wrench ...................................................................... 1
* 9074-365-001 Cover, Cabinet (Top) ................................................................. 1
* 9277-041-011 Insulation Cabinet Cover ......................................................... .1
* 9732-253-001 DDAD Kit for Dryers without Neutral and using 208-240 volt .......... 1
* 9732-102-011 LP Kit for DDAD Dryers ............................................................. 1
* 9555-057-003 Replaceable Lint Screen Fine Mesh Only ................................... .1
* 9277-063-001 Insulation-Front Panel-Top Half ................................................. 2
* 9277-063-002 Insulation-Front Panel-Lower Half .............................................. 2
* 9527-007-001 Stando Wire Saddle ................................................................ 8
* 9544-041-002 Strap - Bead Tie ....................................................................... 1
27 9942-038-005 Vault, Coin Box ............................................................................... 1
* 9545-008-024 Screws, Mounting-Coin Vault ......................................................... 2
28 9807-099-002 Coin Box Assy, Large Blue ...............................................................1
28 9807-099-004 Coin Box Assy, Large Black .............................................................1
* 8640-413-004 Nut, Elastic Stop.................................................................................
80
Part # 8533-090-001 7/21
