Dexter Laundry DC30X2NC-39AC1X User Manual

Rear View
Key Part Number Description Quantity
* 9627-861-001 Wire Harness Overtemperature Switch .............................. 2
* 9801-095-001 Switch Assy, Air Flow ....................................................... 2
1 9539-461-009 Switch, Air Flow ............................................................... 2
2 9029-174-001 Bracket, Switch- Air Flow .................................................. 2
3 9008-007-001 Actuator, Switch ............................................................... 2
4 9451-169-002 Pin, Cotter ....................................................................... 2
5 9545-020-001 Screw 4-40 x 5/8” ............................................................ 4
* 8640-401-001 Nut, Special Twin .#4-40 .................................................. 2
* 9550-169-003 Shield, Switch .................................................................. 2
* 9545-008-001 Screw 10 Bx 1/4” ............................................................. 6
* 9732-205-026 Motor Kit, Blower back, Belt ............................................ 2
7 9376-331-001 Motor, Drive (Marathon) ................................................... 2
* 5191-108-003 Run Capacitor, Motor................................................................1
* 5191-109-003 Start Capacitor, Motor..............................................................1
8 9452-740-001 Plate, Motor Mtg .............................................................. 2
* 9545-029-008 Bolt 3/8” - 16 x 3/4” ......................................................... 8
* 8641-582-003 Lockwash Spring 3/8 ........................................................ 8
9 9545-018-019 Screw, Motor Plate to Back Assy. 1/4-20x 2 1/2 .................. 8
9 86411-582-007 Lockwasher 1/4 ............................................................... 8
9 9538-,163-006 Spacer ............................................................................ 8
9 8641-581-017 Flat Washer 1/4 x 7/8................................................................
9 9209-086-002 Rubber Grommet ............................................................. 8
* 9538-166-006 Grommet Spacers ............................................................ 8
27 9453-157-001 Pulley, Motor ................................................................... 2
* 9545-028-013 Screw, Set ....................................................................... 4
10 9962-017-002 Back Assy, Blower Hsg ..................................................... 2
26 9278-040-001 Impeller, W/Set Screws .................................................... 2
11 9991-053-001 SupportAssy, lntermed. Pulley ........................................... 2
12 9545-029-010 Bolt, Rd Hd 3/8-16 x 1 1/4 ................................................ 6
13 9545-029-003 Bolt, 3/8-16 x 1 1/2 .......................................................... 2
12 8640-415-004 Nut Flange Wiziock 3/8” - 16 ............................................. 6
12 8641-581-035 Washer, Flat .................................................................... 6
14 9861-022-001 Arm Assy-Tension, Complete ............................................. 2
* 8641-581-035 Washer, Flat .................................................................... 2
15 9487-200-003 Ring-Retaining ................................................................. 6
16 9908-039-004 Pulley Assy, Intermediate with bronze ange bearing .......... 2
* 9036-145-002 Bearing - Bronze Flange ................................................... 4
* 9538-164-002 Spacer-Shaft (See Tumbler Group for Expandrd View) ........1
* 9487-234-005 Tolerence Ring .................................................................1
17 9908-049-002 Pulley, Driven ..................................................................1
18 8641-581-026 Washer -Flat ....................................................................1
18 8641-582-016 LockWasher - IntTooth, 1” ................................................1
18 9545-017-009 Screw, 1/2-13x1 1/4 ........................................................1
19 9040-077-001 Belt, Drive- Motor ............................................................ 2
20 9040-073-009 Belt, Drive- Tumbler ......................................................... 2
21 9534-319-002 Spring, Tension ................................................................ 2
22 9099-012-002 Chain, Tension ................................................................. 2
23 9248-,022-002 Hook, Tension ................................................................. 2
* 9125-005-001 Damper Inside Duct Exhaust ............................................ 2
24 9451-146-001 Pin, Damper Hinge ........................................................... 2
* 8520-141-000 Nut, Spring ...................................................................... 4
* 9545-008-026 Screw #10B x 1/2 ............................................................ 6
25 9825-059-001 Cover Duct Upper ............................................................ 1
* 9074-314-001 Cover Duct Lower ............................................................ 1
* 9545-008-024 Screw 10ABx 3/8”...................................................................80
25 9973-030-001 Heat Recirculation Assembly Duct ..................................... 2
90
Part # 8533-090-001 7/21
