T-750 Bolt Torque Chart
Bolt Size Where Used Torque
1/2”x 1 1/4” bolt Tub End of Bearing Hsing. 9545-017-009 70-110 ft/lbs
5/8”x 1 1/2” bolt Tub End of Bearing Hsing. 9545-060-001 120 -150 ft /lbs
1/2”x 1 1/4” bolt Mtg. of Tub to Cradle Asy. 9545-017-009 70-110 ft /lbs
5/8”x 2 1/2”bolt Mtg. of Tub to Cradle Asy. 9545-060-001 120-150 f t /lbs
3/8”x 1 1/2” bolt Tub Back Ring to Tub Back 9545-029-003 45-80 ft/lbs
T-900, T-950 & T-1200 Bolt Torque Chart
Bolt Size Where Used Torque
7/16” Stainless Cap Screw Outer Tub to Bearing Housing 60-80 ft/lbs
3/4 Bolt Bearing Housing to Frame 200-300 ft/lbs
1/2” Bolt Outer Tub Clamping Band to Frame 70-110 ft/lbs
1/2” Bolt Outer Tub Clamping Band - Top 30-40 ft/lbs
3/8” Cap Bolt Driven Pulley to Hub 28-32 ft/lbs
T-1450 Bolt Torque Chart
Bolt Size Where Used Torque
7/16” Stainless Cap Screw Outer Tub to Bearing Housing 60-80 ft/lbs
7/8 Bolt Bearing Housing to Frame 600-650 ft/lbs
1/2” Bolt Outer Tub Clamping Ears to Frame 70-110 ft/lbs
3/8” Cap Bolt Driven Pulley to Hub 28-32 ft/lbs
65
64 65
Part # 8533-075-001 6/22 Part # 8533-075-001 6/22
Notes
