Dexter Laundry WCVD Series User Manual

V-Series Accessories
*WCVD45HC_-12SZ 208-240 volts 60hz. Single Phase or Three Phase
(Parts dierences for the regular door T650 will be found on pages 104-105)
WCVD50HC_-12SZ 208-240 volts 60hz. Single Phase or Three Phase
WCVD60HC_-12 208-240 volts 60hz Single Phase or Three Phase
WCVD60HC_-12SZ 208-240 volts 60hz Single Phase or Three Phase
WCVD80HC_-12 208-240-volts 60hz Single Phase or Three Phase
WCVD90HC_-12SZ 208-240 volts 60 hz Single Phase or Three Phase
Key Description T750 T-900 T950 T-1200 T1450 QTY
* Hose, Water Supply 3/8” I.D.
x 48”
2
* Hose, Water Supply 5/8” I.D.
x 48”
9990-027-013 9990-027-013 9990-027-013 2
Hose, Water Supply 5/8” I.D.
x 48”
9990-027-013 9990-027-013 4
* Washer, Inlet Hose (furnished) 8641-242-000 8641-242-000 8641-242-000 8641-242-000 8641-242-000 2
* Strainer, Inlet Hose (furnished) 9565-003-001 9565-003-001 9565-003-001 9565-003-001 9565-003-001 2
* Bevel Washer for 5/8” bolt used
in installations using angle iron
bases
8641-586-002 8641-586-002
* Bevel Washer for 3/4” bolt used
in installations using angle iron
bases
8641-586-003 8641-586-003 8641-586-003 8641-586-003 8641-586-003 4
* Sealing compound 8538-151-001 8538-151-001 8538-151-0 01 8538-151-001 8538-151- 001 1
* TORX#20 8545-051-002 8545-051-002 8545-051-002 8545-051-002 8545-051-002 1
* Special Tool For Removing Coin
Acceptor Mounting Screws. (T-
10 Torx)
8545-051-003 8545-051-003 8545-051-003 8545-051-003 8545-051-003 1
* Flow Restrictors (in dispenser ) 9475-002-002 9475-002-002 9475-002-003 9475-002-003 9475-002-003 2
* Battery (used on Control PCB) 8612-001-001 8612-001-001 8612-001-001 8612-001-001 8612-001-001 1
* Special Tool for adjusting spac-
ing between outer tub front and
cylinder front
8545-056-001 8545-056-001 8545-056-001 8545-056-001 8545-056-001 1
* VFD Filter options (1 phase)
120v
1
* VFD Filter options (3 phase) 9732-255-001 9732-255-001 9732-255-001 9732-256-001 9732-255-001 1
* VFD Filter options (1 phase) 9732-230-001 9732-230-001 9732-230-001 9732-251-001 9732-230-001 1
* Puller for pushing cylinder out
of bearings must be purchased
from local sources.
1
* Clamps to hold tub front to
outer tub when installing tub
front
Vise Grip #11R Vise Grip #11R Vise Grip
#11R
Vise Grip #11R Vise Grip
#11R
1
* Coin Bearing & Seal Kit 9732-219-006 9732-219-006 9732-219-006 9732-219-006 9732-219-006 1
* Coin Op CD with OS2 Platform
for A Series Washers Only
9504-015-001 9504-015-001
Key Service Lock (6324) 6292-006-007 6292-006-007 6292-006-007 6292-006-007 6292-006-007 1
Key, Program (N561) 6292-006-013 6292-006-013 6292-006-013 6292-006-013 6292-006-013 1
* Mode Light Support 9635-022-001 9635-022-001 9635-022-001 9635-022-001 9635-022-001 1
* MS300 VFD Display 9150-058-001 9150-058-001 9150-058-001 9150-058-001 9150-058-001 1
Kits, Assemblies, & Common Parts
Loading Door & Door Lock Components Part Number
Door Glass Gasket (Large Door) 9206-431-001
Door Glass Gasket (Standard Door) 9206-419-001
Door Handle Only (Small) 9244-080-003
Door Close Switch 9539-492-001
Door Lock Gear Motor Assembly 9892-015-001
Kit - Door Latching Assy. & Cam (replaces original Door Latching Assembly) 9732-347-001
Kit - Door Cam Replacement 9732-346-002
Kit - Locking Pawl Replacement 9732-346-001
Kit - Door Gasket Expander Kit (Small) 9732-139-001
Kit - Door Gasket Expander Kit (Large) 9732-139-002
Electrical Components Part Number
Transformer, Main 8711-004-001
Transformer, Control 8711-009-001
Main Control Board 9473-004-009
Kit, Electronic Pressure Sensor 9732-314-001
VFD & Breaking Resistors Components Part Number
Breaking Resistor 200 Ohms 9483-004-002
Breaking Resistor 160 Ohms 9483-004-003
Delta E Drive Display 9150-044-001
MS 300 VFD Display 9150-058-001
Data Cable (56”) 9806-015-003
Drain & Water Valve Components Part Number
Kit - 3” Drain Valve Seal Replacement 9732-327-001
Drain Valve 3” 9379-202-001
Water Valve (Dual) 9379-183-012
Water Valve (Single Mueller) 9379-194 -001
Diaphragm (Dual) 9118-049-003
Diaphragm (Single Mueller) 9118-055-001
Cabinet Components Part Number
Front Panel Screw 9545-008-014
Front Panel Finisher Washer 8641-585-001
Front Panel Spring Nut 8640-399-008
Top Soap Box Screw (Regular Chassis Only) 9545-008-012
Top Soap Box Spring Nut (Regular Chassis Only) 8640-399-007
5/16 Hex Screw, Common 9545-008-026
Top Lock Key #6324 9306-025-001
Cylinder Plug (1.5” Plastic) 9456-041-007
86 87
Part # 8533-075-001 6/22 Part # 8533-075-001 6/22
