Key Description T-650 QTY
* Loading Door, Complete #1-10 9960-274-002 1
1 Loading Door, Ring 9487-265-001 1
2 Gasket, Loading Door 9206-419-001 1
3 Window, Loading Door 9635-016-001 1
* Shaft Assy, Locking (includes 4
thru 7)
9913-134-003 1
4 Shaft, Door Locking 9537-195-002 1
5 Cam, Locking 9095-040-002 1
6 Pin, Groove (1 1/4) 9451-181-005 1
7 Pin, Groove (3/4) 9451-181-004 1
Retaining Ring (c-clip) 8649-031-000 1
8 Spring, Lock Cam 9534-360-002 1
9 Handle, Door 9244-080-003 1
20 Pin, Door Handle (groove) 9451-181-006 1
* Screw, Hinge Mtg 5/16” x 3/4” 9545-014-009 3
* Lockwasher 5/16” Ext tooth 8641-582-009 3
* Shim, Loading Door Hinge, Thin 9552-036-001 AR
10 Door Hinge Assembly Mounts to
Tub Front
9955-029-002
13 Screw, Loading Door Mtg (5/16”
TF)
9545-056-001 3
* Rubber Edge (mounts to Front
Panel)
9059-063-002 1
* Nut, Keps 8640-413-002 4
* Wiring Harness doorlock safety
switch assembly
9627-791-0 04 1
18 Black Wire Door Close Switch 8220-063-026 1
Red Wire Door Close Switch 1
18 Wires Black 8220-062-028 1
12 Loading Door Hinge Clamp w/
pin
9938-040-002 1
* Loading Door Hinge Clamp (No
Hinge Switch Pin) (NEW Style)
9079-122-003 1
Loading Door and Panel Dierences For
T650 Express - 45lb Express Machine
108 109
Part # 8533-075-001 6/22 Part # 8533-075-001 6/22
Notes
108
