ConnectCore for i.MX51
©2011DigiInternational,Inc. 104
PoE Connector (power out), P18
The table below provides the pinout of the PoE output connector:
Pin Signal
1+12V_PoE
2+12V_PoE
3GND
4GND
5 PoE_GND
6 PoE_GND
