ConnectCore for i.MX51
©2011DigiInternational,Inc. 54
Cable Specification: U.FL/W.FL to RP-SMA
Attributes
Dimensions
Note:
Dimensions are provided for reference purposes only. The actual antenna might vary.
1 = U.FL
2 = RP-SMA
Note:
This module obtained its complete certification by using the cable described here. End
users in North America should use a cable that matches these specifications to maintain the
module’s certification.
Attribute Property
Impedance 50 Ohm
Frequency Range 0 to 6 GHz
Length 150 mm
Temperature Range -40° to +90° C
Loss 3.8dB/m (3 GHz)
5.6dB/m (6 GHz)
