ConnectCore for i.MX51
©2011DigiInternational,Inc. 126
Antenna Specification: 802.11b/g antenna
Attributes
Dimensions
Note:
Dimensions are provided for reference purposes only. The actual antenna might vary.
Attribute Property
Frequency 2.4 ~ 2.5GHz
Power Output 2W
DB Gain 2dBi
VSWR < or = 2.0
Dimension 108.5 mm % 10.0mm
Weight 10.5g
Temperature Rating -40 °to +80° C
Part Number DG-ANT-20DP-BG
