ConnectCore for i.MX51
©2011DigiInternational,Inc. 84
Standard JTAG ARM Connector, X13
The standard JTAG ARM connector is a 20-pin header and can be used to connect
development tools (ICS) such as Ronetix PEEDI or other.
Note:
In order to enable ETM functionality, Digi offers an optional ETM adapter board (sold
separately, Digi P/N CC-ACC-MX51-ETM). Please contact us.
Pin Function Pin Function
1 +1.8V 2 +3.3V
3 JTAG_TRST# 4 GND
5 JTAG_TDI 6 GND
7 JTAG_TMS 8 GND
9 JTAG_TCK 10 GND
11 Reserved (RTCK) 12 GND
13 JTAG_TDO 14 GND
15 JTAG_RESET# 16 GND
17 JTAG_DE# 18 GND
19 GND 20 GND
