ConnectCore for i.MX51
©2011DigiInternational,Inc. 78
Ethernet 2, Connector J17
The table below shows the pinout of the Ethernet 2 expansion connector.
Pin Signal Pin Signal
1 GND 2 GND
3 ETH2_TX+ 4 ETH2_RX+
5 ETH2_TX- 6 ETH2_RX-
7 GND 8 GND
9 Reserved (ETH2_DC+) 10 Reserved (ETH2_DD+)
11 Reserved (ETH2_DC-) 12 Reserved (ETH2_DD-)
13 GND 14 GND
15 ETH2_ACTIVITY# 16 ETH2_LINK#
17 - 18 -
19 - 20 -
21 - 22 -
23 - 24 -
25 - 26 -
27 - 28 -
29 - 30 -
31 - 32 -
33 - 34 -
35 - 36 -
37 - 38 -
39 - 40 -
