ConnectCore for i.MX51
©2011DigiInternational,Inc. 133
Current measurement in Minimum configuration
Current measurement in Typical configuration
Power Mode Power Supply Current Draw Comments
Full load +3.7V Battery 700mA
+5V supply to charger 680mA
ON +3.7V Battery 420mA
+5V supply to charger 410mA
User Idle +3.7V Battery 420mA
+5V supply to charger 410mA
System Idle +3.7V Battery 380mA
+5V supply to charger 390mA
Suspend +3.7V Battery 145mA
+5V supply to charger 170mA
Power Mode Power Supply Current Draw Comments
Full load +3.7V Battery 1450mA
+5V supply to charger 1250mA
ON +3.7V Battery 1150mA
+5V supply to charger 950mA
User Idle +3.7V Battery 1075mA
+5V supply to charger 890mA
System Idle +3.7V Battery 350mA
+5V supply to charger 350mA
Suspend +3.7V Battery 145mA
+5V supply to charger 170mA
