Digi ConnectCore Series User Manual

ConnectCore for i.MX51
©2011DigiInternational,Inc. 140
The following table shows the PMIC_INT DC parameters.
The following table shows the PMIC_PWGTDRV DC parameters.
The following table shows the PMIC_LED DC parameters.
The following table shows the PMIC_SE DC parameters.
The following table shows the Ethernet DC parameters.
Parameter Symbol Min Typ Max Unit
Supply Voltage VDD 2.5 2.775 3.1 V
High-level output voltage Voh VDD-0.2 - VDD V
Low-level output voltage Vol - - 0.2 V
Output driver impedance Rout 200 - 500
Ω
Parameter Symbol Min Typ Max Unit
High-level output voltage Voh 5 5.4 5.4 V
Low-level output voltage Vol - - 0.1 V
Load Current Iout - - 100 nA
Parameter Symbol Min Typ Max Unit
Input current Iled 0 - 21 mA
Parameter Symbol Min Typ Max Unit
Supply Voltage VDD 2.5 2.775 3.1 V
High-level output voltage Voh 1 - VDD V
Low-level output voltage Vol - - 0.3 V
Input pull-up impedance Rup - 100 - k
Ω
Parameter Symbol Min Typ Max Unit
Differential Output Voltage High
100BASE-Tx
Vpph 950 - 1050 mV
Differential Output Voltage Low
100BASE-Tx
Vppl -950 - -1050 mV
