DG-BG1000 User Manual
44
Parameter Description
WAN IP Settings
Type
You can choose Fixed IP or DHCP.
If select Fixed IP, you should enter the local IP
address, remote IP address and subnet
mask.
If select DHCP, the router is a DHCP client, the
WAN IP address is assigned by the remote
DHCP server.
Local IP Address
Enter the IP address of WAN interface provided by
your ISP.
Gateway Enter the gateway IP address provided by your ISP.
Netmask Enter the subnet mask of the local IP address.
Unnumbered
Select this checkbox to enable IP unnumbered
function.
Add
After configuring the parameters of this page, click it
to add a new PVC into the Current ATM VC Table.
Modify
Select a PVC in the Current ATM VC Table, then
modify the parameters of this PVC. After finishing,
click it to apply the settings of this PVC.
Current ATM VC Table
This table shows the existed PVCs. It shows the
interface name, channel mode, VPI/VCI,
encapsulation mode, local IP address, remote IP
address and other information. The maximum item
of this table is eight.
Click it, and the PPP Interface-Modify page
appears. You can modify the PVCs’ parameters.
Click
in the PPPoE mode, the page shown in the following figure appears. In
this page, you can configure parameters of this PPPoE PVC.
