DG-GS1528HP/C User Manual
20
（4）Broadcast storm control page
Figure 20 is the Broadcast Storm Control page. This page is used to do the suppression for configure port
broadcast packets, multicast packets and DLF packet.
From the Port drop-down bar select to configure ports. Through the on and off key to open and close the port
broadcast suppression, multicast, DLF inhibition and suppression. Inhibition rate is used to configure the port inhibition
speed, range 1-1024000, unit Kbits. The inhibition rate of the same port broadcast suppression, multicast and DLF
inhibition is the same.
Figure 20 Broad cast Storm control Page
（5）Port speed limits page
Figure 21 is the port speed- limit page. This page is used to configure the port ‘send and receive rate
From the Port drop-down bar select the configure ports. Bandwidth control of the send data packets is used to
configure and display the bandwidth control , the range is 1-1024000, unit kbits, enter into force after the key press
applications. If the port is not configured bandwidth control, shown as off. Cancel button is used to cancel the
corresponding data packet to send bandwidth control. Receiving data packets is used to configure and display the
bandwidth control of receive data packets control , the range is 1-1024000, unit kbits, enter into force after the key
press applications. If the port is not configured bandwidth control, shown as off. Cancel button is used to cancel the
corresponding receiving data packets bandwidth control
