DG-WA30002NP User Manual
39
Below are the descriptions of different modes supported by Access Point.
Modes Description
AP Access Point mode, allows wireless clients to
connect to Access Point and exchange data with
the devices connected to the wired network.
Station-
Infrastructure
Enables the Ethernet devices such us TV and Game
player connected to the Access Point to a wireless
client.
AP Bridge-Point to
Point
Establishes wireless connection with another
wireless Access Point using the same mode. It
links the wired network which these two wireless
Access Points are connected to. Only one Access
Point can be connected in this mode.
AP Bridge-Point to
Multi-Point
Establishes wireless connection with other wireless
Access Points using the same mode. It links the
wired network which these wireless Access Points
are connected to. Up to four Access Points can be
connected in this mode.
AP Bridge-WDS This mode is similar to ‘AP Bridge to Multi-Point’,
but the Access Point does not work only in a
bridge-dedicated mode, but also will be able to
accept wireless clients while the Access Point is
working as a wireless bridge.
Universal Repeater This product can act as a wireless range extender
that will help you to extend the wireless network.
The Access Point can act as Station and AP at the
same time. It can use Station function to connect to
a Root AP and use AP function to service all
wireless clients within its coverage.
Please select one wireless operating mode. For detailed description of every
operating mode; please refer to Section
2-4-1 to 2-4-6 listed below.
