DG-WA30002NP User Manual
89
4. Appendix
4-1 Hardware Specification
Flash: 2MB
SDRAM: 16MB
LAN Port: 10/100M UTP Port x 1
Antenna:
PiFa antenna x 2 (2T2R MIMO technology)
Power: 5VDC, 2A Switching Power Adapter
Frequency Band: 2.4000 ~ 2.4835 GHz
Data Rate: IEEE 802.11b (1/2/5.5/11Mbps)
IEEE 802.11g (6/9/12/24/36/48/54Mbps)
IEEE 802.11n (20 MHz) MCS 0-15, up to 144 Mbps
IEEE 802.11n (40 MHz) MCS 0-15, up to 300 Mbps
Net Dimension: 105 (L) x 105 (W) x 46 (H) mm
Gross Dimension: 212(L) x 132 (W) x 65 (H) mm
Net Weight : 143gms
Gross Weight : 450gms
Transmit Power:
11n (20 MHz) @ MCS 15: 23 +/- 1.5 dBm
11n (40 MHz) @ MCS 15: 23 +/- 1.5 dBm
11g @ 54 Mbps : 24 +/- 1.5 dBm
11b @ 11Mbps : 26 +/- 1.5 dBm
Operating Temperature: 0 ~ 40°C
Storage Temperature: -20 ~ 60°C
Operating Humidity: 10-90% (Non-Condensing)
Storage Humidity: Max. 95% (Non-Condensing)
