SmartSource Elite Series - Installation & Operations Guide
May 2019 8227 4907-005 Page 27 of 37
This felt pad is large enough to absorb all the ‘priming ink’ that will be used in the normal lifetime of the
machine. However, if it does become saturated or dirty, it can be replaced. Open the front cover and snap
out the felt assembly downwards, as shown.
The replacement felt pad assembly slides in upwards and ‘snaps’ into place.
Replacement felt assemblies are available from Digital Check, www.digitalcheck.com, part number 8227
4203-000 for the 4-line Inkjet. Single line Inkjet replacement felt assembly part number is 82275914-000.
Both assemblies are replaceable as in the above description on the swing-out right cover.
