Digital Projection E-Vision Laser 7500, 8500 & 10K Series
Reference Guide
APPENDIX B: SUPPORTED SIGNAL INPUT MODES
Rev D August 2017
Standard
Resolution
V-Freq
(Hz)
V-Total
H-Freq
(kHz)
HDMI1/2
DisplayPort /
DVI-D
HB
Dual-pipe HDMI
(*1)
HB
DisplayPort
(*1)
Output Display
Frame Rate (Hz)
Remarks
1080p50 Side-by-Side (Half) 1920x1080 50.00 1125 56.25
ü ü
100 *3
1080p59 Side-by-Side (Half) 1920x1080 59.94 1125 67.43
ü ü
120 *3
1080p60 Side-by-Side (Half) 1920x1080 60.00 1125 67.50
ü ü
120 *3
1080p50 Top-and-Bottom 1920x1080 50.00 1125 56.25
ü ü
100 *3
1080p59 Top-and-Bottom 1920x1080 59.94 1125 67.43
ü ü
120 *3
1080p60 Top-and-Bottom 1920x1080 60.00 1125 67.50
ü ü
120 *3
1080p50 Frame Sequential 1920x1080 50.00 1125 56.25
ü ü
100 *3
1080p59 Frame Sequential 1920x1080 59.94 1125 67.43
ü ü
120 *3
1080p60 Frame Sequential 1920x1080 60.00 1125 67.50
ü ü
120 *3
1080p100 Frame Sequential 1920x1080 100.00 1125 112.50
ü
100 *2,
*3
1080p120 Frame Sequential 1920x1080 120.00 1125 135.00
ü
120 *2,
*3
WUXGA_100_RB Frame Sequential 1920x1200 100.00 1258 125.72
ü
100 *3
WUXGA_120_RB Frame Sequential 1920x1200 120.00 1271 152.40
ü
120 *2,
*3
1080p23 Dual Pipe 1920x1080 23.98 1125 26.97
ü
96 *4
1080p24 Dual Pipe 1920x1080 24.00 1125 27.00
ü
96 *4
1080p25 Dual Pipe 1920x1080 25.00 1125 28.13
ü
100 *3
1080p30 Dual Pipe 1920x1080 30.00 1125 33.75
ü
120 *3
1080p50 Dual Pipe 1920x1080 50.00 1125 56.25
ü
100 *3
1080p59 Dual Pipe 1920x1080 59.94 1125 67.43
ü
120 *3
1080p60 Dual Pipe 1920x1080 60.00 1125 67.50
ü
120 *3
WUXGA_60_RB Dual Pipe 1920x1200 60.00 1235 74.04
ü
120 *3
Notes
Remarks:
*1: HB(High Bandwidth) mode
without warping/blending.
*2: 8-bit / color.
*3: Frame drop at scaler and frame
doubling at formatter. Sources
greater than 60 fps are processed
at half the frame rate, then frame
doubled.
*4 Output display frame rate up to
96Hz for 24Hz 3D input
