Digital Projection E-Vision Laser 7500, 8500 & 10K Series
Operating Guide
USING THE PROJECTOR
Rev D August 2017
Using The Projector
Main menu
• Input
Press ENTER/OK to open the list of available inputs.
Use the UP and DOWN arrow buttons to select an input from the list, then press
ENTER/OK to conrm your choice.
Press EXIT to return to the main menu.
• Test Pattern
Choose from:
...Off, White, Black, Red, Green, Blue, CheckerBoard, CrossHatch, V Burst, H
Burst, ColorBar...
Use the LEFT and RIGHT arrow buttons to switch between values.
• Lens, Image, Color, Geometry, Edge Blend, 3D, Laser, Setup and Network
Press ENTER/OK to open these menus and access various settings.
Press the DOWN arrow at the bottom of the page to access additional menus:
• PIP and Information
Press ENTER/OK to open these menus and access various settings.
Press the UP arrow to return to the previous page.
Notes
See Signal Inputs in the
Connection Guide for further
information about the available
inputs and connections.
Selecting a test pattern hides the
OSD. Press EXIT to hide the test
pattern, and then press MENU to
show the OSD.
Main menu, page 1 and 2
Main Menu
Test Pattern
Lens
Input
Geometry
Edge Blend
Color
3D
Setup
Network
Laser
q
u
HDMI 1
u
u
u
u
u
u
u
u
Main Menu
PIP
Information
p
u
u
