Digital Projection E-Vision Laser 8500 Series Installation And Quick Start Guide

page 71
Digital Projection E-Vision Laser 7500, 8500 & 10K Series
Operating Guide
USING THE PROJECTOR
Rev D August 2017
PIP menu
• PIP
Turn PIP on and off.
• Source
Select an input source for the PIP image.
Any combinations are possible between main and PIP input source, as long as the
two inputs are not from the same group:
Group 1 Group 2
HDMI 1 HDMI 2
DVI VGA
DisplayPort COMP
HDBaseT 3G-SDI
• Position
Set the location of the PIP image on the screen. Choose from Top-Left, Top-Right,
Bottom-Left, Bottom-Right and PBP.
Notes
Some settings may be unavailable
depending on other settings. For
more information, see Possible
Combinations Of Settings further
in this guide.
PIP
Source
Position
PIP
HDMI1
Top-Left
Off
