page 45
Digital Projection E-Vision Laser 7500, 8500 & 10K Series
Operating Guide
USING THE PROJECTOR
Rev D August 2017
Geometry menu
This menu allows you to compensate
for image distortions caused by an
unusual projection angle or irregular
screen surface.
Aspect Ratio
This feature denes the aspect ratio of the source. Use the Screen Setting feature (Setup menu) to dene the scren aspect ratio.
If you choose a preset aspect ratio from here, it will give you the best t for your selection.
Choose from:
• 5:4
• 4:3
• 16:10
• 16:9
• 1.88
• 2.35
• TheaterScope
• Source
• Unscaled
Notes
Some settings may be unavailable
depending on other settings. For
more information, see Possible
Combinations Of Settings further
in this guide.
This menu differs slightly between
E-Vision Laser projectors: there
is an additional menu, Arc, on
E-Vision Laser 10K.
See next page for further information
about the TheaterScope aspect
ratio.
Geometry
Digital Zoom
Overscan
Aspect Ratio
Blanking
4 Corners
Rotation
Keystone
Pincushion / Barrel
Custom Warp
u
Off
Source
u
u
u
u
u
Off
Arc
u
Geometry, E-Vision Laser 10K
Geometry, E-Vision Laser 7500 & 8500
Geometry
Digital Zoom & Shift
Overscan
Aspect Ratio
Blanking
4 Corners
Rotation
Keystone
Pincushion / Barrel
Custom Warp
u
Off
Source
u
u
u
u
u
Off
