Digital Zoom & Shift (E-Vision Laser 7500 and 8500)
Digital zooming enlarges a section of the image, while the area outside the enlarged
section is cropped out to preserve the overall image size.
• Digital Zoom denes the level of zoom that needs to be applied. If Digital Zoom is
set to 0, then the other settings in the menu will be disabled.
• Digital Pan and Digital Scan specify the area that is being enlarged:
• Digital Pan adjusts the horizontal coordinates.
• Digital Scan adjusts the vertical coordinates.
Digital Zoom (E-Vision Laser 10K)
This menu features the same settings as the Digital Zoom & Shift menu on the E-Vision
Laser 7500 and 8500 OSD.
In addition it has a Reset command, which restores the default Digital Zoom,
Digital Pan and Digital Scan values.
Notes
Some settings may be unavailable
depending on other settings. For
more information, see Possible
Combinations Of Settings further
in this guide.
Digital Zoom & Shift
Digital Zoom
Digital Scan
Digital Pan
0
0
0
Digital Zoom
Digital Zoom
Digital Scan
Digital Pan
0
0
0
Reset
To Next Page
