page 104
Digital Projection E-Vision Laser 7500, 8500 & 10K Series
Reference Guide
APPENDIX C: WIRING DETAILS
Rev D August 2017
Appendix C: Wiring Details
RS232
9 way D-type connector
1 unused
2 Transmitted Data (TX)
3 Received Data (RX)
4 unused
5 Signal Ground
6 unused
7 unused
8 unused
9 unused
Notes
RS232:
pin view of female connector
