DigiTech RP1000 - MANUAL 2 User Manual

11
Amp Loop with Pre-Amp In Line
Connect the RP1000’s
1/4” Line Outputs to the
Power Amp inputs.
POWER AMP WITH SPEAKER CABS
PREAMP
Connect the
RP1000 Amp
Loop Send to
the External
Preamp Input.
Connect the
External Preamp
Line Out to the
RP1000 Amp Loop
Return.
Connect your guitar
to the RP1000’s Input.
Amp/Mixer switch on 1/4"
outputs is set to AMP.
Stomp Loop
Connect the RP1000’s
Left (mono) Line Output
to the amp’s Input.
Connect the
RP1000 Stomp
Loop Send to the
stompbox Input.
Connect the
stompbox Output
to the RP1000
Stomp Loop Return.
Connect your guitar
to the RP1000’s Input.
Amp/Mixer switch on 1/4"
outputs is set to AMP.

DigiTech RP1000 - MANUAL 2 Specifications

General

Inputs	1/4" Instrument
Outputs	1/4" Headphone
USB	Yes
MIDI	Yes
Expression Pedal	Yes
Display	LCD
Power Supply	Included
