Parts list for circuit diagram
www.dilo-gmbh.com | 1001-S01.bae
Gas mixing device SF
6
/ CF
4
Pos. Designation Order-no. Piece
F01 Cut-out 05-0725-R003 1
F51 Microprocessor controller 05-0701-R003 1
K01 SPS S7-1214C 05-1657-R003 1
Onboard module 05-1657-R012 1
K02 Extension module 05-1657-R033 1
K03 Router 05-1829-R001 1
K51 Motor contactor 05-0722-R002 1
Q51 Motor protection circuit breaker 05-0891-R011 1
Q02 Motor protection circuit breaker 05-0891-R006 1
Q51 Motor protection circuit breaker 05-0891-R011 1
Auxiliary switch 05-0723-R004 1
R3 Heating band 05-1091-R001 5 m
Connecting kit 05-1091-R002 1
S04 Flip switch 1 pole 05-0467-R001 1
T01 Universal transformer 05-0747-R008 1
T02 Power unit 05-1461-R103 1
U01 Discharger 230V 05-1509-R001 1
X03 Socket 05-0753-R014 1
Range of operating voltage:
208-240V 60 Hz
Control voltage: 230V
Evaporator:
4.80 kW 12.5 A
Control: 0.70 kW 0.8 A
