Dilo SF6 - Page 83

Spare parts list
www.dilo-gmbh.com | 1002-S01.bae
Gas handling unit
Pos. Designation Article-no. Piece
11 Compressor (50Hz) 4-200-00 1
21 15 m³/h suction pump B105R51 1
31 40 m
3
/h vacuum pump (nominal suction capacity,
final vacuum  1 mbar)
3-690-R007 1
Wire-braided hose SM0120L00750 1
51 Evaporator K032R01 1
101 Coupling groove part DN20 VK/A-02/20 P 1
102 Coupling groove part DN20 VK/A-02/20 P 1
103 Coupling groove part DN20 VK/A-02/20 P 1
105 Flange coupling DN20 VK/FL-01/20 T 1
107 Coupling groove part DN8 VK/A-02/8 P 1
108 Coupling groove part DN8 VK/A-02/8 P 1
111 Dry filter 3-899-R002 1
121 Particle filter DN20 3-377-R020 1
122 Particle filter DN40 K072R21 1
123 Filter with connection 3-337-R002 1
131 Solenoid valve DN20 05-1718-R160 1
132 Solenoid valve DN20 05-1718-R201 1
133 Solenoid valve DN20 05-1718-R201 1
134 Solenoid valve K132R11 1
135 Solenoid valve DN10 05-1718-R102 1
136 Solenoid valve DN10 05-1718-R102 1
137 Solenoid valve K132R11 1
138 Block 3-1011-01 T 1
151 Control valve DN20 K066R05 1
152 Control valve K066R05 1
161 Gauge 05-1643-R001 1
162 Gauge 05-0486-R031 1
163 Gauge 05-1239-R002 1
164 Gauge 05-0486-R031 1
171 Conical non return valve DN20 VR/A-03/20 P 1
172 Conical non return valve DN20 VR/A-02/20 P 1
181 Pressure reducer 3-300-R003 1
182 Pressure reducer 3-301-R002 1
191 Safety valve 05-0110-R100 1
