DFW series indicators DFW_03_12.07_EN_U
23
MODE
- It carries out a specific function of the operating mode set in the set-up environment.
- In the numeric input phase it selects the digit to be modified, from left to right.
- In totalizator modes, if pressed twice consecutively, it allows to enter in a specific menu to set
the parameters of the totalizations.
ENTER / PRINT
- It carries out a specific function of the operating mode set in the set-up environment.
- In the numeric input phase, it confirms the entry made.
- In the SET-UP, it allows to enter a step or to confirm a parameter within a step.
- It transmits the data from the serial port dedicated to the printer.
C / i
- It turns the instrument on and off.
-
In the numeric input phase, it quickly zeros the present value.
- In the SET-UP, it allows to exit a step without confirming the change made
in the 5-key indicator:
- Allows viewing the scale’s metric information: capacity, division, minimum weigh for each
configured range.
