3.3.8 Advanced Configuration
1. Port Group
Figure 3-3-26 Port Group
Figure 3-3-27 Port Group Add
Table 3-3-11 Port Group Add
Index
Priority of the port group :1-7, 1 is highest priority value.
Description
Descript the port group
Primary/Secondary SIP User ID
SIP count number
Primary/Secondary Authenticate ID
SIP user name which registers to soft switch/SIP server
Primary/Secondary Authenticate
Password
SIP password which registers to soft switch/SIP server
Select Mode
There four options: Ascending, Cyclic Ascending,
Descending, Cyclic Descending
Port
Port0-port7, By checking the different ports to form a port
group
