OPERATION
67
OPERATION PRACTICAL ADVICE
WARNING: A forage harvester can pose a severe health risk if not used properly. Make sure the safety rules are
followed by everyone operating the machine or in its vicinity. Refer to SAFETY RULES, page 12.
NOTE: With safety in mind, we suggest to perform a general inspection and adjustment verification before starting the
harvester.
HARVESTER DRAW BAR POSITION
Maintain the draw bar (item 1) as straight as possible (as close to 90° as possible) when operating in the field to reduce
the drive shaft angles. This will increase the life of the universal joints and reduce vibrations. Also, with a straighter draw
bar position, trailers being pulled behind the harvester will track better.
Figure 78 Harvester drawbar
STOPPING THE MACHINE
It is essential to familiarize yourself with the controls and safety rules. It is essential to know how to stop the machine
before starting it. Refer to page 70, section STOPPING THE HARVESTER.
FIELD WORK
To set the harvester in harvesting mode:
1. Release the spout lock by pushing on the lock handle (item 1) to allow ring gear movement.
Figure 79 Spout unlock
