11
© 2009 Directed Electronics. All rights reserved.
➢ Door lock harness, 3-pin connector
1
BLUE (-) UNLOCK OUTPUT
2
EMPTY NOT USED
3
GREEN (-) LOCK OUTPUT
➢ Remote start harness (H2) wiring diagram
H2/1
BLACK/WHITE (-) NEUTRAL SAFETY SWITCH INPUT
H2/2
VIOLET/WHITE TACHOMETER INPUT WIRE
H2/3
BROWN (+) BRAKE SWITCH SHUTDOWN WIRE
H2/4
GRAY (-) HOOD PINSWITCH SHUTDOWN WIRE
H2/5
BLUE/WHITE (-) 200mA 2ND STATUS/REAR DEFOGGER OUTPUT
