PINK/WHITE (+) PROGRAMMABLE OUTPUT FOR ACCESSORY OR IGNITION
Connect this wire to the second ignition or accessory wire in the vehicle.
(Selectable by using menu 2 feature 6.)
Note:
For vehicles that do not have a second ignition or accessory
wire, this connection is not required.
Remote start harness (H2), 5-pin connector
H2/1
BLACK/WHITE (-) NEUTRAL SAFETY SWITCH INPUT
Connect this wire to the toggle (override) switch as shown in Figure A.
Connect the other wire from the toggle switch to the PARK/NEUTRAL
switch in the vehicle. This wire will test with ground with the gear selector
either in PARK or NEUTRAL. This will prevent the vehicle from accidentally
being started while in a drive gear. This input MUST rest at ground in order
for the remote start system to operate. Connected properly the vehicle will
only start while in PARK or NEUTRAL.
In some vehicles, the PARK/NEUTRAL position switch activates a fac-
tory starter lock-out that will not allow the starter to operate in a drive
gear. In these vehicles, connect this wire to the toggle switch as shown
in Figure B (See next page). Connect the other wire from the toggle
switch to chassis ground.
