Remote control learn routine
The system comes with two remote controls that have been taught to the
receiver. The receiver can store up to 4 different remote control codes
in memory. Use the following learn routine to add remote controls to
the system.
The Program switch, plugged into the blue port, is used for program-
ming. There is a basic sequence of steps to remember whenever pro-
gramming this unit: Key, Choose, Transmit and Release.
1. Key. Turn the ignition to the ON position.
2. Choose. Within 10 seconds, press and release
the Program switch the number of times correspond-
ing to the desired channel listed next. Once you
have selected the channel, press the switch once
more and
HOLD it. The LED will flash to confirm
the selected channel. Do not release the Program
switch.
Channel Function
1
Auto Learn Standard Configuration (default)
The auto learn configuration automatically sets up the remote's button
configuration.
2
Delete remotes: This feature erases all remotes from the memory of the
system. This is useful in cases when a customer’s remote is lost or stolen.
Note: This does not reset the programmed features of the system or reset
the Virtual Tach setting.
