What is included
• The control module (see diagram)
• HX antenna receiver
• Two remote controls
• A push-button Valet switch
• A hood pinswitch
• A shut-down toggle switch
AVISTART 4113
Red 4 pin D2D/Bitwriter port
4-pin satellite harness
5-pin remote start
harness
9-pin main harness
4-pin/3-wire
receiver port
3-pin/2-wire door
lock harness
2-pin BLUE
program plug
Status LED
6-pin relay output
