Operating settings learn routine
The System Features Learn Routine dictates how the unit operates. The
programmable operating settings of this unit can be changed when-
ever necessary through the computer-based Learn Routine. The Pro-
gram push-button switch, plugged into the blue port, is used with a
programmed remote control to change the settings. You can access and
change all of the feature settings using the Program switch. To program
settings, remember: Key, Choose, Transmit and Release.
To enter the learn routine:
1. Key. Turn the ignition on and then back off.
2. Select menu. Press and hold the Program switch.
When the LED flashes once and the horn honks
once, Menu One has been selected. Continue to
hold the switch until the LED flashes twice and the horn honks twice.
Menu Two has now been selected. Release the Program switch after
the desired Menu choice has been selected.
3. Choose. Within 10 seconds, press and release
the Program switch the number of times correspond-
ing to the feature number you want to program.
(See Features Menu section.)
Once the Program switch has been pressed and released the desired
number of times, press it once more and
HOLD it. After a second,
the LED will flash to indicate which feature you have accessed. For
example, groups of eight flashes would indicate access to the status
output feature (Feature 8).
4. Transmit. The remote control is used to select the
desired setting. Pressing

will set it to the LED
