H2/3
BROWN (+) BRAKE SWITCH SHUTDOWN WIRE
This wire MUST be connected to the vehicle’s brake light wire. This is
the wire that shows (+) 12V when the brake pedal is depressed. The
remote start will be disabled or shut down any time the brake pedal is
depressed.
H2/4
GRAY (-) HOOD PINSWITCH SHUTDOWN WIRE
This wire MUST be connected to the hood pinswitch. This input will
disable or shut down the remote start when the hood is opened.
H2/5
BLUE/WHITE (-) 200mA 2ND STATUS/REAR DEFOGGER OUTPUT
This wire supplies a 200mA output as soon as the module begins the
remote start process. This wire can also be used to activate the defog-
ger trigger (latched/pulsed) 10 seconds after successful remote start.
(See Menu 2 Feature 8, in the
Feature Descriptions
section in this
guide for details about programming this output.)
