933.GM9 2.46.198.9 2022 Chevrolet Equinox (Smart Key)
©2023 Directed. All rights
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color Connection
H2/16 Red/Blue No Connection No Connection
H2/17 Black/White (-) E-Brake Input No Connection
H2/18 Orange/Black (+) Instant Alarm Input No Connection
H2/19 Blue (-) Trunk Input No Connection
H2/20 Green (-) Door Input No Connection
H2/21 Gray
(-) Hood Switch Input [1]
The installation of an aftermarket hood pin is only required on vehicles
that are not equipped with a factory hood pin or if not supported in
data.
H2/22 Violet/White (AC) Tach Input No Connection
Main harness, 12-pin black connector (H3)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color Connection
H3/1 Blue/White Relay - N.C. - Immo. Data Interrupt (vehicle side) BCM in center console front passenger side, green 25 pin plug, pin 2 Data Green/Violet
Remote Start
Only
H3/2 Blue/Red Relay N.O. - No Connection No Connection
H3/3 Blue Relay COM. - Immo. Data Interrupt (conn. side) BCM in center console front passenger side, green 25 pin plug, pin 2 Data Green/Violet
Remote Start
Only
H3/4 White/Brown Relay N.C. - No Connection No Connection
H3/5 White Relay COM. - No Connection No Connection
H3/6 Red (+) 12 Volt Input BCM in center console front passenger side, blue 27 pin plug, pin 4 + Red/Brown (20A)
Mandatory
H3/7 Lt. Green/Red
Relay N.O. - (-) Ground [3]
Must use a 180 Ohm resistor.
Hook up brake for automatic transmission vehicles or clutch for manual
transmission vehicles, not both.
(chassis ground)
Remote Start
Only
H3/8 Lt. Green
Relay COM. - (MUX) Clutch Activation Output [3]
Not Applicable
Hook up brake for automatic transmission vehicles or clutch for manual
transmission vehicles, not both.
Remote Start
Only
H3/9 Lt. Green/White Relay N.C. - No Connection No Connection
H3/10 Black (-) Ground (chassis ground)
Mandatory
H3/11 White Relay COM - No Connection No Connection
H3/12 Red (+) 12 Volt Input BCM in center console front passenger side, blue 27 pin plug, pin 4 + Red/Brown (20A)
Mandatory
Relay harness, 10-pin white connector (H4)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color Connection
H4/1 N/A No Connection No Connection
H4/2 Red/Black (+) 12 Volt Input No Connection
H4/3 Pink/Black (+) Flex Relay Output No Connection
H4/4 Pink/White No Connection No Connection
H4/5 Red (+) 12 Volt Input No Connection
H4/6 Green Starter Disable (conn. side) No Connection
To Next Page
