933.GM9 2.46.198.9 2022 Chevrolet Equinox (Smart Key)
©2023 Directed. All rights
Vehicle connections
The connection information listed below is specific to the 2022 Chevrolet Equinox (Smart Key). Refer to “Pre-installation and application warnings” for a list of important notes.
Data harness, 8-pin white connector (H1)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color Connection
H1/1 Tan (Data) HS CAN Low BCM in center console front passenger side, white 26 pin plug, pin 24 Data White
Mandatory
H1/2 Tan/Black (Data) HS CAN High BCM in center console front passenger side, white 26 pin plug, pin 25 Data Blue
Mandatory
H1/3 Orange/Brown No Connection No Connection
H1/4 Orange/Green No Connection No Connection
H1/5 Lt. Green (Data) Single Wire CAN BCM in center console front passenger side, blue 27 pin plug, pin 22 Data Green
Mandatory
H1/6 Violet/Brown
(MUX) Brake Activation Output [3]
BCM in center console front passenger side, blue 27 pin plug, pin 7
Hook up brake for automatic transmission vehicles or clutch for manual
transmission vehicles, not both.
MUX Blue/Yellow
Remote Start
Only
H1/7 Orange/Black No Connection No Connection
H1/8 Yellow/Black (Data) Immo. Data (conn. side) BCM in center console front passenger side, green 25 pin plug, pin 2 Data Green/Violet
Remote Start
Only
Analog input/output harness, 22-pin white connector (H2)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color Connection
H2/1 Lt. Green/Black (-) Parking Light Output BCM in center console front passenger side, white 26 pin plug, pin 22 - Green/Gray
Mandatory
H2/2 Blue/White
(-) Ground When Armed (GWA) Output [4]
Starter:
Starter Motor --or-- Underhood Fuse Box, gray 60 pin plug (X3), pin
34
Ignition:
BCM in center console front passenger side, green 25 pin plug, pin 6
Must use a relay.
Must use a 1N4002 diode or larger.
+
+
Yellow
Violet/Black
Security Only
H2/3 Dk. Green/Black (-) Lock Output No Connection
H2/4 Red/White (-) Trunk Release Output No Connection
H2/5 Brown/Black (-) Horn Output BCM in center console front passenger side, brown 26 pin plug, pin 19 - Brown/White
Optional
H2/6 Brown/White (-) AUX 1 Output No Connection
H2/7 White (+) AUX 1 Output No Connection
H2/8 Violet/Black (+) AUX 2 Output No Connection
H2/9 Dk. Blue/Black (-) Unlock Output No Connection
H2/10 Lt. Blue/Black (-) Factory Alarm Disarrn Output No Connection
H2/11 Brown/Red
(+) Siren Output [2]
The siren is only required when enabling the security features during
module flashing.
Security Only
H2/12 Pink (+) Ignition Sense Input No Connection
H2/13 Violet (+) Door Input No Connection
H2/14 Brown (+) Brake Input No Connection
H2/15 White/Blue (-) Activation Input No Connection
To Next Page
