Users can set the threshold of low battery warnings in the app.
RTK Functions
The T30 has an onboard D-RTK. The heading reference of the aircraft from the dual antennas of the
onboard D-RTK is more accurate than a standard compass sensor and can withstand magnetic
interference from metal structures and high-voltage power lines. When there is a strong GNSS signal,
the dual antennas activates automatically to measure the heading of the aircraft.
The T30 supports centimeter-level positioning to improve agricultural operation when used with the DJI
D-RTK 2 Mobile Station. Follow the instructions below to use the RTK functions.
Enable/Disable RTK
Before each use, make sure that the aircraft RTK positioning function is enabled and the RTK signal
source is correctly set to either D-RTK 2 Mobile Station or Network RTK. Otherwise, RTK cannot be used
for positioning. Go to Operation View in the app, tap , and select RTK to view and set.
Make sure to disable the aircraft RTK positioning function if not in use. Otherwise, the aircraft is not able
to take off when there is no differential data.
Using with the DJI D-RTK 2 Mobile Station
1. Refer to the D-RTK 2 Mobile Station User Guide for more information about completing the linking
between the aircraft and the mobile station and setting up the mobile station.
2. Power on the mobile station and wait for the system to start searching for satellites. The RTK status
icon on top of the Operation View in the app shows
to indicate that the aircraft has obtained and
used the differential data from the mobile station.
Using with the Network RTK Service
The Network RTK service uses the remote controller instead of the base station to connect to an
approved Network RTK server for differential data. Keep the remote controller on and connected to the
internet when using this function.
1. Make sure that the remote controller is connected to the aircraft and has access to the internet.
2. Go to Operation View in the app, tap
, and then RTK. Set the RTK signal source to Custom Network
RTK, and input the network information.
3. Wait for the remote controller to be connected with the Network RTK server. The RTK status icon on
top of the Operation View in the app shows
to indicate that the aircraft has obtained and used the
RTK data from the server.
Aircraft LEDs
There are LEDs on the frame arms marked M1 to M6. The LEDs on M2 and M6 are front LEDs and
glow red during ight to indicate the front of the aircraft. The LEDs on M3 and M5 are rear LEDs and
glow green during ight to indicate the rear of the aircraft. The LEDs on M1 and M4 are aircraft status
LEDs. They are turned off when the aircraft is in ight and indicate the aircraft status when the aircraft is
grounded.
