Weight and Balance and Equipment List
Users can remove the spray tank and install the spreading system for spreading operations. The center
of gravity is within the ranges listed in the Center of Gravity Limitations section whether a spray tank or
spreading system is used.
Handling, Servicing and Instructions for Maintenance
and Continued Airworthiness
Ground Handling
1. Make sure that the aircraft is powered off. Remove the battery from the aircraft and store it properly.
2. Check the aircraft structure, clean the dirt and dust, and replace any loose or damaged parts.
3. Clean the residue in the spray/spread tank and the spraying/spreading system and keep the system
dry.
4. Make sure that the aircraft is folded correctly for transportation or storage.
5. Make sure that the battery connector on the aircraft is clean and dry.
Disassembly, Storage, and Reassembly
The tank, propellers, and nozzles on the aircraft can be disassembled. Follow the instructions below to
disassemble, reassemble, and store them. Make sure to remove the Intelligent Flight Battery from the
aircraft before disassembly and reassembly.
Tank
Disassembly
1. Remove the bottom cover on the front of the aircraft. Pry the bottom cover from the gap between the
bottom cover and the rest of the aircraft using a tool if required. Be careful not to damage the cover.
2. Remove the spray tank:
a. Unplug the liquid level gauge cable from the port at the bottom of the aircraft front, attach the
cover of the port, and remove the cable from the cable strainer at the bottom of the aircraft.
b. Use the double-ended wrench included in the aircraft package to remove the two nuts that
secure the aircraft and T-shaped connector on the spray tank, detach the T-shaped connector,
and attach the stopper to the hoses on the aircraft.
c. Lift and remove the spray tank on the aircraft.
To Next Page
